Context
Sports-betting "tip" sites have a credibility problem, and it's almost always the same three failures: unvalidated models (accuracy quoted from one lucky split), naive edge math (comparing a model probability to raw book odds, ignoring the vig), and no accountability (picks published, then quietly forgotten). CrownWager was built to be defensible on all three — a cross-validated model, explicit Decimal money math, and a track record graded against reality.
Constraints
It's a ground-up rebuild of a legacy monolith that scored 2.3/10 on a twelve-dimension assessment, so hardening was a first-class requirement, not a follow-up. And it's a responsible-gambling product, which constrains the assistant on purpose.
System architecture
Three decoupled services so heavy ML never blocks web requests: a Django/DRF backend, a separate FastAPI ML service in its own container, and a Next.js frontend. Django never imports XGBoost — all inference happens over HTTP, and a model registry serves only a model whose checksum is validated, otherwise a clearly-labeled baseline.
System map
Tap to inspect
- 01
The frontend; talks to Django over REST + JWT.
- 02
Implied prob, edge, expected value, and half-Kelly staking — all in Decimal, no float drift.
- Instead of
- Float arithmetic (the legacy approach)
- Why
- Odds/EV/Kelly/arbitrage math accumulates float error — 1/1.91 + 1/1.95 doesn't land on exactly 1.00, so a narrow arbitrage can be missed. Every money calculation uses Decimal(str(value)) and quantizes to the cent. Staking is half-Kelly (0.5) — professional practice, ~50% less variance than full Kelly.
- Tradeoff
- Decimal is 2–3× slower than float — imperceptible on a single prediction, and worth it for money math.
The backend: odds, EV/Kelly, best bets, graded record, and CrownBot — heavy ML never runs in-process.
Every pick grades against the real final score; per edge tier; flagged insufficient below 20 settled picks.
- Instead of
- Backfilling or interpolating outcomes that can't be mapped
- Why
- A pick graded wrong inflates or deflates the model's record. Unmappable picks are voided, not guessed. Results settle against real final scores, are broken out per edge tier (0–2%, 2–5%, 5–10%, 10%+) to expose lucky buckets, and the record is flagged 'insufficient' until 20 picks settle.
- Tradeoff
- Voiding shrinks the sample, so the record builds slowly — but it's honest.
Claude, grounded strictly in the current best bets; forbidden from pushing wagers or promising profit.
- 03
Shallow model (max_depth 3) predicting NBA moneyline; accuracy from 5-fold stratified CV.
- Instead of
- A neural net, and the legacy 'best of 300 random splits' 68% claim
- Why
- The inherited claim was cherry-picked after the fact, never validated. XGBoost was chosen for reproducibility (one fixed split + 5-fold stratified CV → 65.2% ± 0.8% on 15,115 games vs a 57.5% base rate), interpretability (depth capped at 3, real feature importances), and fast JSON serving. Honesty over a marginal, unverifiable accuracy gain.
- Tradeoff
- 65% isn't state-of-the-art — but it's a number that holds up.
Inference over HTTP /predict; Django never imports XGBoost.
- Instead of
- Importing the ~500 MB ML stack into the Django web process
- Why
- Embedding XGBoost/TensorFlow in the web process makes every request thread carry the weight, and a slow model starves web workers. The model runs as a separate FastAPI service; Django calls it over HTTP (15s timeout) behind a circuit breaker — after 3 consecutive failures it fails fast for 30s and serves a labeled baseline instead of hanging.
- Tradeoff
- Two services to deploy and a network hop — bought decoupling, independent scaling, and zero downtime on model updates.
Validates checksums; serves only a model flagged validated:true, else a labeled baseline.
- Instead of
- Serving whatever model binary is on disk
- Why
- The model is promoted only if it clears a threshold on held-out data and its SHA-256 checksum matches the manifest. If no validated model is present, the service returns a transparent, documented baseline (home-court + rating + rest logits) — never vaporware.
- Tradeoff
- A gate between training and serving — deliberate friction that keeps unproven models out of production.
- 04
Odds, bets, and graded results; Celery + Redis for async jobs and cache.
Hover a node to preview · click one to see the decision behind it
Use the arrow keys, Home, or End to move between nodes. Press Enter or Space to pin a node's decision, and Escape to release it.
- Next.js 15: The frontend; talks to Django over REST + JWT.
- Django + DRF: The backend: odds, EV/Kelly, best bets, graded record, and CrownBot — heavy ML never runs in-process.
- EV / Kelly: Implied prob, edge, expected value, and half-Kelly staking — all in Decimal, no float drift. Why: Odds/EV/Kelly/arbitrage math accumulates float error — 1/1.91 + 1/1.95 doesn't land on exactly 1.00, so a narrow arbitrage can be missed. Every money calculation uses Decimal(str(value)) and quantizes to the cent. Staking is half-Kelly (0.5) — professional practice, ~50% less variance than full Kelly. Instead of: Float arithmetic (the legacy approach). Tradeoff: Decimal is 2–3× slower than float — imperceptible on a single prediction, and worth it for money math.
- Graded record: Every pick grades against the real final score; per edge tier; flagged insufficient below 20 settled picks. Why: A pick graded wrong inflates or deflates the model's record. Unmappable picks are voided, not guessed. Results settle against real final scores, are broken out per edge tier (0–2%, 2–5%, 5–10%, 10%+) to expose lucky buckets, and the record is flagged 'insufficient' until 20 picks settle. Instead of: Backfilling or interpolating outcomes that can't be mapped. Tradeoff: Voiding shrinks the sample, so the record builds slowly — but it's honest.
- CrownBot: Claude, grounded strictly in the current best bets; forbidden from pushing wagers or promising profit.
- FastAPI ML: Inference over HTTP /predict; Django never imports XGBoost. Why: Embedding XGBoost/TensorFlow in the web process makes every request thread carry the weight, and a slow model starves web workers. The model runs as a separate FastAPI service; Django calls it over HTTP (15s timeout) behind a circuit breaker — after 3 consecutive failures it fails fast for 30s and serves a labeled baseline instead of hanging. Instead of: Importing the ~500 MB ML stack into the Django web process. Tradeoff: Two services to deploy and a network hop — bought decoupling, independent scaling, and zero downtime on model updates.
- Model registry: Validates checksums; serves only a model flagged validated:true, else a labeled baseline. Why: The model is promoted only if it clears a threshold on held-out data and its SHA-256 checksum matches the manifest. If no validated model is present, the service returns a transparent, documented baseline (home-court + rating + rest logits) — never vaporware. Instead of: Serving whatever model binary is on disk. Tradeoff: A gate between training and serving — deliberate friction that keeps unproven models out of production.
- XGBoost: Shallow model (max_depth 3) predicting NBA moneyline; accuracy from 5-fold stratified CV. Why: The inherited claim was cherry-picked after the fact, never validated. XGBoost was chosen for reproducibility (one fixed split + 5-fold stratified CV → 65.2% ± 0.8% on 15,115 games vs a 57.5% base rate), interpretability (depth capped at 3, real feature importances), and fast JSON serving. Honesty over a marginal, unverifiable accuracy gain. Instead of: A neural net, and the legacy 'best of 300 random splits' 68% claim. Tradeoff: 65% isn't state-of-the-art — but it's a number that holds up.
- PostgreSQL: Odds, bets, and graded results; Celery + Redis for async jobs and cache.
Data flow
A request hits Django, which calls the ML service's /predict for a home-win probability, turns it into fair-odds edge and expected value, sizes a stake with half-Kelly, and persists the pick. When the game is final, the pick is graded against the real score.
Key decisions
Cross-validated accuracy over a lucky split
Instead of: report a single train/test split, quote accuracy without measuring it
The XGBoost model is trained deterministically and reported from 5-fold stratified cross-validation, and kept intentionally shallow (max_depth 3) to resist overfitting — a real edge above the base home-win rate.
Trade-off accepted — A shallow model leaves some accuracy on the table versus an aggressively-tuned one — in exchange for a number you can trust.
Explicit, Decimal-precise edge and staking math
Instead of: float arithmetic, full Kelly staking
Implied prob is 1/odds, edge is model − implied, EV is explicit, and stakes use half-Kelly — all in Decimal so real-money arithmetic doesn't drift.
Trade-off accepted — Half-Kelly grows a bankroll slower than full Kelly, deliberately, to survive variance.
A verifiable, graded track record — not a wall of pending picks
Instead of: show pending picks and hope, backfill an impressive history
Every pick settles only once its game is FINAL with both scores; results aggregate per edge tier and are flagged 'insufficient' below 20 settled picks; unmappable picks are voided.
Trade-off accepted — The record starts empty and grows slowly — the price of it being real.
Graceful degradation everywhere
Instead of: let a slow dependency hang the request
A circuit breaker on the ML client, plus fallbacks for the odds API and the assistant, keep the product running (in labeled demo mode) even if every external dependency is down.
Trade-off accepted — More fallback code to maintain, for a system that never hard-fails in front of a user.
A grounded assistant over a persuasive one
Instead of: a salesy chatbot that pushes wagers
CrownBot is grounded strictly in the current best bets; its prompt forbids telling anyone to place a wager, forbids promising profit, and mandates responsible-gambling messaging.
Trade-off accepted — A less 'salesy' assistant — which is the entire point for this domain.
What failed
A slow or dead ML service used to block web requests while their calls timed out. The fix was a circuit breaker: after three consecutive failures it opens and fast-fails for thirty seconds, falling back to clearly-labeled demo predictions instead of hanging.
Cause — a slow or dead ML service blocked web requests on timeouts
Fix — circuit breaker opens after 3 failures, fast-fails 30s, and drops to labeled demo predictions
Performance & cost
| Metric | Value | Method |
|---|---|---|
| accuracy (CV) | 65.2% ± 0.8% | 5-fold stratified cross-validation on 15,115 NBA games (2012–24), one fixed random split — no cherry-picking. The base home-win rate in the data is 57.5%, so this is a real ~8-point edge. |
| held-out test | 64.3% | 80/20 hold-out on 3,023 unseen games; ROC-AUC 0.685, log-loss 0.628 — the calibration signal that keeps Kelly staking from over-sizing. |
| model shape | 106 features · depth 3 | 750 shallow trees (max_depth 3, learning rate 0.01) over 106 pre-game features; kept deliberately shallow to resist overfitting and stay interpretable. |
| track record | graded vs finals | Picks settle only on FINAL scores; aggregated per edge tier; unmappable picks voided; flagged insufficient below 20 settled picks. |
| money math | Decimal | Edge, EV, and half-Kelly (0.5) staking in Decimal; arbitrage flagged when Σ(1/odds) < 1, legs sized to equalize payout. |
| legacy → rebuild | 2.3/10 → hardened | A twelve-dimension assessment drove a rebuild with per-IP rate limiting, admin 2FA, CSP, and blocking bandit + gitleaks in CI. |
Operations
Celery + Redis run the async jobs; the ML service runs in its own container behind the circuit breaker. Security is hardened by default: proxy-aware per-IP rate limiting, constant-time token comparison, optional TOTP 2FA, DSN-gated Sentry, and a tested backup/restore runbook.
What I'd do differently
The model is deliberately simple; with more graded history I'd add calibration reporting (are the 60% picks actually winning 60%?) and a closing-line-value check, which is a stronger signal of edge than raw win rate.
Evidence
The app is live and the backend, ML service, and grading logic are in the repository above.
Changelog
A verifiable model track-record and prediction confidence grades; cut a cherry-picked split in a reality pass.
Best-bets credibility layer — fair odds, confidence grades, and filters.
Security hardening: admin 2FA, cookie-JWT auth, a circuit breaker on the AI client, and blocking CI gates.
Card-free free-tier deploy (Hugging Face Space + Vercel), bankroll ROI/P&L tracking, and launch hardening.
First build — a validated XGBoost NBA moneyline model served behind the analytics platform.
